| ÖZM 550 LXF | ÖZM 700 LXF | ÖZM 850 LXF | ÖZM 1000 LXF | |
| CAPACITY | 250 pcs/min | 250 pcs/min | 250 pcs/min | 250 pcs/min |
| BAG WIDTH | 80-520 mm | 80-680 mm | 80-800 mm | 80-980 mm |
| BAG LENGTH | 80-1000 mm | 80-1000 mm | 80-1000 mm | 80-1000 mm |
| BAG THICKNESS | 0,020-0,100 mm | 0,020-0,100 mm | 0,020-0,100 mm | 0,020-0,100 mm |
| QTY OF SERVO MOTORS | 4 pcs | 4 pcs | 4 pcs | 4 pcs |
| TOTAL POWER | 11 kw | 11 kw | 11 kw | 11 kw |
| MACHINE WIDTH | 1450 mm | 1600 mm | 1750 mm | 1950 mm |
| MACHINE LENGTH | 5815 mm | 5815 mm | 5815 mm | 5815 mm |
| MACHINE HEIGHT | 1890 mm | 1890 mm | 1890 mm | 1890 mm |
| MACHINE WEIGHT | 1600 kg | 1800 kg | 1900 kg | 2000 kg |
STANDARD FEATURES
- Thanks to the touch operator panel, the bag size, the number of bags, the production speed, the number of bags in the package can be seen, the number of stops in the total count.
- There is 1 photocell for cutting printed and unprinted bags
- Servo motor controlled pulling rollers help cutting at high speed and with the desired measurement precision.
- Thanks to the servo motor controlled welding jaw, strong and quality welding is ensured.
- Thanks to the servo motor controlled belt system, the belts work synchronously to the stacking system.
- Stoper roller system with servo motor controlled for better stacking
- Warp rolls inverter tension control systems
- With pneumatic ballerina system
- Automatic edge control systems
- Automatically stops when the roll is finished
- Photocell stops automatically when printing place is not correct
- Bobbin diameter max 800 mm
- Ability to work in PP, OPP, CPP, High Density Polyethylene ( HDPE ), Low Density Polyethylene ( LDPE )
STANDARD EQUIPMENT
- PE side welding (digging) jaw
- PP side welding (digging) jaw
- Tape apparatus
- Stack conveyor
- Pneumatic bobbin lift
