AA Film Machine
| |
ÖZM Ø 80 LBN 1300D 2A |
ÖZM Ø 90 LBN 1700D 2A |
| MATERIAL |
LDPE |
LDPE |
| SCREW DIAMETER |
Ø 80 mm |
Ø 90 mm |
| DIE HEAD SYSTEM |
Fixed |
Fixed |
| DIE HEAD |
Ø 300 mm |
Ø 350 mm |
| TOWER |
Rotary |
Rotary |
| TOWER HEIGHT |
8000 mm |
8000 mm |
| WINDER |
Back to back, non-stop |
Back to back, non-stop |
| ROLLER WIDTH |
1300 mm |
1700 mm |
| FILM WIDTH (Min-Max) |
400-1200 mm |
500-1600 mm |
| FILM THICKNESS (Min-Max) |
0,018-0,200 mm |
0,018-0,200 mm |
| MAIN MOTOR |
45 kw |
55 kw |
| TOTAL POWER |
99,8 kw |
109,8 kw |
| CAPACITY |
250 kg/h |
300 kg/h |
STANDARD EQUIPMENT
- Raw material absorber - 1 piece
- Air shaft – 2 pcs
- Banana roller - 2 pcs
- Side cutting attachment - 1 set
- Pressure sensor - 1 piece
OPTIONAL EQUIPMENT
